If you push a diesel engine too hard, you will immediately realize that power without thermal management will lead to engine failure. EGT, which stands for exhaust gas temperature, indicates how close to the limit you are operating the engine. This is one of the costliest errors one could make while building a high-output engine, simply ignoring this parameter.
Contents
The Danger Zone is Real, and it Has a Number
Most experienced diesel drivers choose 1,250°F as the maximum temperature they can sustain while the engine is under stress. This is not a random number. According to performance and maintenance recommendations provided by Cummins, sustained exhaust gas temperatures of 1,300°F or more are believed to increase the risk of piston crown deformation and turbocharger fatigue.
This is because the aluminum pistons used in many modern, high-output diesels begin to soften when temperatures reach or exceed 1,250-1,300°F. Should you surpass 1,500°F, even for a short amount of time, you are risking structural damage to both pistons and exhaust valves. The danger of this limit is that sometimes the damage may not be immediately obvious. Heat weakens metal incrementally over whole heating and cooling cycles, and it only takes the manifold of most engines to go through this process on its own.
Why Tuning Raises the Stakes
Adding more fuel allows for more power, but not in the same proportion. It sounds good, but the tradeoff is that excess fuel can cause overheating issues. The first problem you face is running rich, which means too much fuel for the available oxygen in the combustion process. The unburned fuel will of course spill over and exit the exhaust, creating heat. This will lead to a spike in exhaust gas temperatures (EGTs) and cause the turbo to soot up. Particularly vulnerable is the variable geometry turbo, as the vanes controlling exhaust gas flow can stick or warp due to the high heat and carbon deposits.
Monitoring Tools and Where to Put Them
Using a pyrometer is the best way to monitor your EGTs in real-time. Estimating based on RPM, your right foot, or just when the pedal starts to melt isn’t ideal if you’re pushing it while hauling.
Installing your EGT probe where the turbine housing joins the exhaust manifold is often suggested as the closest-to-the-head, fastest-response, highest-reading option. The turbo extracts thermal energy from the exhaust stream which can mask some potential problems and give you a falsely low number. Upstream of the turbo flange, it’s naked in there, so issues like DPF regen can increase the temperature of the gases and potentially expose your sensor to particulate.
Knowing how hot is too hot will depend on your specific setup or tuning if you’ve modified anything that affects how much fuel is pumped and not burned. A quality 6.7 cummins tuner gives you a live data interface where you can set EGT alerts, monitor boost and fueling simultaneously, and keep the engine from de-rating unexpectedly during a long tow. A lifted truck with oversize tires and an aggressive tune is going to see a lot more heat at a lot lower absolute temperature than a flat bumper truck.
The Cool-Down Period Isn’t Optional
The one habit that consistently separates people who keep their turbos for 200,000 miles from those who replace them every few years is easy: after driving the snot out of their truck, the first group leaves the engine idling for two or three minutes. Just long enough for the turbocharger bearing housing, center section, and internal bearing system to cool down.
Turbochargers work by siphoning off waste heat from the exhaust stream and repurposing it to compress intake air. Since the housings and internal bearing system see nearly unimaginable turbine speeds, sealing them off from the exhaust stream during low-load or no-load operation is impossible. This means the bearings are bathed in hot oil under operation.
Shut the engine off immediately after a hard pull or extended high-speed run and the bearings are soaked in heat without the benefit of that cooling, flowing oil. Heat transfers from the bearing into the surrounding components and cooks the oil, leaving behind deposits on the bearing surfaces. This process is known as coking. Over time these deposits build up and the corresponding increase in bearing clearances overworks and ultimately destroys the bearings.
The turbocharger won’t make exactly the same power after 500 miles, much less 200,000, if the bearings weren’t able to cool, glide, and rotate as designed. Cleared for two to three minutes of idle, no-load or low-load operation, the turbine wheel will slow down more or less according to plan.
Heat is the Variable That Connects Everything
Any change in your vehicle that increases power is a potential threat to your engine in the form of increased heat. Diesel engines that operate at higher EGTs, like those that are modified to produce more power, are at increased risk of experiencing thermal failure. Diesel engine EGTs can be as high as 1,500 degrees F. Steels used in the exhaust system and turbocharger housings can experience significant degradation at these temperatures.
